Frequently asked questions about this product
1. Is the sensor installed before delivery?
The sensor assembly is shipped with the body, and the customer needs to install it after arrival.
2. How to replace linear modules between different brands?
It is necessary to understand what brand of servo, lead screw, guide rail the customer uses, the width of the module, the base size of the profile and the installation hole position. It can also be processed and designed completely according to the customer's original hole position, as long as the drawing is provided.
3. What is the service life of a single-axis robot?
The service life usually refers to the length of time it can work normally and stably. This length of time is related to many factors such as the design, manufacturing quality, use conditions and maintenance of the module.
4. What are the types of common linear modules according to the transmission method?
Timing belt type: The transmission method of the linear module is assisted by belts and linear guides. Features Fast speed and large stroke.
Ball screw type: The transmission method of the linear module is assisted by ball screws and linear guides.
Features Relatively high load and accuracy, high transmission efficiency, and low friction resistance.
5. How to replace linear modules between different brands?
We need to know what brand of servo, lead screw, guide rail the customer uses, the width of the module, the base size of the profile and the installation hole position. We can also design and process according to the original hole position of the customer, as long as the drawing is provided.
